BDA36060 New SQUARE D Circuit Breaker,Standard,3 Poles,60A,

USD 712.50 USD

SKU: srCSUk4p

Brand: Square D

MPN: BDA36060

Condition: New – Open box

Tags: 14 AWG 2.97" 2/0 AWG 25 kA 347/600VAC 5.16" 60 A 60/BD 9.70" ABC BDA36060 Circuit Breaker Fixed I-Line Load Side Lug Not Rated PowerPact B Square D Standard Thermal Magnetic UL,IEC,CCC,EAC,CSA,NOM

Categories: Circuit Breakers & Disconnectors

Specifications

Phase Connection	ABC
Circuit Breaker Type	Standard
Terminal Connection	Load Side Lug
Max. Wire Size	2/0 AWG
AC Voltage Rating	347/600VAC
MPN	BDA36060
Depth	5.16"
Item	Circuit Breaker
Height	9.70"
Width	2.97"
Maximum Amperage	60 A
Trip Type	Thermal Magnetic
Max. AIR Rating	25 kA
Current Rating	60 A
Min. Wire Size	14 AWG
Standards	UL,IEC,CCC,EAC,CSA,NOM
Brand	Square D
Mounting	I-Line
Series	PowerPact B
DC Voltage Rating	Not Rated
Instantaneous Trip	Fixed
Frame Size	60/BD

A nice touch is the Square D brand, and you will find that it looks clean on the front of the panel.
